2MR Mono
A mono phono cartridge with a nude spherical R18 µm stylus, meant for playing mono microgroove LP records. Its narrow housing suits low-profile tonearms such as Rega's without spacers or modification.
- Mono cartridge for microgroove LPs
- R18 µm nude spherical stylus on aluminium cantilever
- Strapped output works with any stereo phono stage
- Low-profile housing for Rega-style tonearms
- 4 mV output, 1.8 g recommended tracking force
- Half-inch mount, two-screw fitting
Fotky
7Inzeráty
Tento model zatím nikdo neinzeruje
Až někdo bude prodávat 2MR Mono, inzeráty a historie prodejů se objeví tady.
Prodat stejnýPopis
The 2MR Mono is a moving magnet cartridge made for mono microgroove LPs. It carries a nude spherical diamond stylus with an 18 µm tip radius on an aluminium cantilever, and has a nominal output of 4 mV.
The motor uses quad coils and split pole pins. The output is strapped so both sets of pole pins deliver the same signal, which allows true mono playback on an ordinary stereo phono stage without mono-specific equipment.
The housing is narrow and low in profile, designed for turntables and tonearms such as Rega that need a low-form-factor cartridge. It fits without modifications or spacers under the tonearm and mounts with two screws in a half-inch mount. The recommended tracking force is 1.8 g, with a range of 1.6 to 2.0 g, and the cartridge weighs 6 g.
Video
Specifikace
- Značka
- Ortofon
- Model
- 2MR Mono
- Kategorie
- DJ vybavení › Přenosky a hroty
Electrical
- Output voltage at 1 kHz, 5 cm/sec
- 4 mV
- Internal impedance, DC resistance
- 700 Ohm
- Internal inductance
- 350 mH
- Recommended load resistance
- 47 kOhm
Audio
- Frequency response 20 Hz - 20 kHz
- + 3 / - 1 dB
- Tracking ability at 315 Hz
- 70 µm
- Compliance, dynamic, lateral
- 18 µm/mN
Stylus
- Stylus type
- Nude Spherical
- Stylus tip radius
- R18 µm
- Cantilever material
- Aluminium
- Stylus colour
- White
Tracking
- Tracking force range
- 1.6-2.0 g (16-20 mN)
- Tracking force, recommended
- 1.8 g (18 mN)
- Tracking angle
- 20°
Physical
- Cartridge body material
- Polymer and aluminum
- Cartridge colour
- Black/White
- Cartridge weight
- 6 g
- Mounting type
- Half inch mount
